Vehicle Applications
-
2024–2026 Toyota Tacoma 2.4L Turbo
-
2025–2026 Toyota 4Runner 2.4L Turbo
- 2024–2026 Toyota Land Cruiser 2.4L Turbo i-FORCE MAX
Features / Oil Catch Can
- U.S. Patents: D870,785 S / D870,786 S
- Direct-fit application with custom bracket, fittings, and hose
- Includes pre-cut high-performance vacuum hose
- Designed to work with supplied OEM-style factory fittings
- Includes vehicle-specific mounting bracket and hardware
- Closed-loop design integrates with the PCV/CCV system to help separate oil vapor and contaminants
- Constructed from lightweight 6061 aircraft-grade aluminum
- Easy-drain NPT plug
- Optional remote quick-drain valve available
- Oil capacity up to 150 ml
- Customizable insert rings available in 8 colors
- Available in carbon fiber for reduced weight and enhanced engine-bay appearance
- Approximate size: 4.30 in. high x 2.50 in. diameter
- Limited Lifetime Warranty
Features / Triple Twister Chamber
- ADD W1 specially engineered Triple Twister Chamber designed to improve oil and moisture separation
- Multi-stage internal baffling helps capture oil vapor and contaminants
- High-flow internal design helps maintain proper PCV/CCV system operation
- Fully serviceable filter and catch can
- Helps reduce oil buildup in the intake manifold, intercooler, throttle body, and related components
- Cleaner intake air can help support more consistent engine performance
- Designed to keep oil and moisture out of the intake system under both normal and high-load driving conditions
Description
The ADD W1 Oil Catch Can is engineered to help reduce the oil vapor, moisture, and contaminants carried through the PCV or CCV systems before they are recirculated back into the the system
Its dual-port design works in-line with the factory ventilation system, while the internal Triple Twister baffled chamber helps slow and redirect blow-by gases so oil and moisture can separate and collect at the bottom of the can.
Unlike many air-oil separator systems that return collected fluid back into the engine, the ADD W1 catch can stores contaminants separately, helping keep unwanted oil residue and moisture out of the intake tract.
The result is a cleaner intake system with reduced buildup in areas such as the intake manifold, intercooler, throttle body, and intake valves.
The Triple Twister internal design is engineered to increase contact time inside the can, helping improve separation efficiency while maintaining airflow through the PCV/CCV system.
Easy to install, easy to service, and built for long-term use, the ADD W1 Oil Catch Can is designed for drivers looking to improve engine cleanliness and maintain performance over time.
